MSI B550M PRO-VDH WIFI Motherboard
MSI B550M PRO-VDH WIFI Motherboard - Image 2
MSI B550M PRO-VDH WIFI Motherboard - Image 3
MSI B550M PRO-VDH WIFI Motherboard - Image 4
MSI B550M PRO-VDH WIFI Motherboard - Image 5

MSI B550M PRO-VDH WIFI Motherboard

Feature Specification
Platform AMD
Socket AM4
CPU Support AMD Ryzen 5000, Ryzen 4000G, Ryzen 3000 Series
Chipset B550
Memory Type DDR4
Max Memory 128 GB
Memory Speed Up to 4400+ MHz
Channel Supported Dual Channel
Memory Features Supports non-ECC UDIMM, ECC UDIMM (non-ECC mode), un-buffered memory
Graphics Ports 1 × VGA, 1 × DisplayPort, 1 × HDMI
Expansion Slots 1 × PCIe 4.0/3.0 x16 (PCI_E1), 2 × PCIe 3.0 x1
Wireless Networking Wi-Fi AC, Bluetooth 2.1
Back Panel I/O Ports VGA, HDMI, DisplayPort, USB 3.2 Gen 1 5Gbps ×2, USB 2.0 ×1, LAN, PS/2 Keyboard/Mouse, Flash BIOS Button, Wi-Fi Antenna connectors, 3 × Audio jacks
Form Factor Micro-ATX
Warranty 3 Years

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

Original price was: ₹17,400.00.Current price is: ₹9,899.00.

Add to compare
Add to wishlist
12 People watching this product now!
  • Pick up from the Woodmart Store

To pick up today

Free

  • Courier delivery

Our courier will deliver to the specified address

2-3 Days

Free

  • DHL Courier delivery

DHL courier will deliver to the specified address

2-3 Days

Free

  • Warranty 1 year

More details

  • Free 30-Day returns

More details

Payment Methods:

Description

MSI B550M PRO-VDH WIFI Motherboard

Important Notice:

  • BIOS update may be required to support the latest Ryzen processors (up to 5th Gen).
  • Maximum supported memory speed depends on the Ryzen CPU generation.
  • For complete compatibility information, check the manufacturer’s website.

Features

  • Supports AMD Ryzen™ 5000 & 3000 Series desktop processors (not compatible with Ryzen™ 5 3400G & Ryzen™ 3 3200G) and AMD Ryzen™ 4000 G-Series processors.
  • Supports DDR4 memory up to 4400(OC) MHz.
  • Lightning-fast experience with PCIe 4.0, Lightning Gen4 x4 M.2, and M.2 Shield Frozr.
  • Premium thermal solution with 7W/mK thermal pads, additional choke thermal pad, and M.2 Shield Frozr for high-performance and nonstop usage.
  • Powerful design featuring Core Boost, Digital PWM IC, 2oz thickened copper PCB, Creator Genie, and DDR4 Boost.
  • Audio Boost delivers studio-grade sound quality.
  • Dragon Center software integrates all MSI exclusive tools with a user-friendly interface.



Category Specification
Model B550M PRO-VDH WIFI
CPU Support AMD Ryzen 5000 & 3000 Series, AMD Ryzen 4000 G-Series (not compatible with Ryzen™ 5 3400G & Ryzen™ 3 3200G)
Chipset AMD B550
Memory 4 × DDR4 slots, up to 128GBSupports DDR4 1866–3200 MHz (JEDEC)Supports DDR4 2667–4400+ MHz (A-XMP OC)Dual channel architectureSupports non-ECC UDIMM, ECC UDIMM, un-buffered memory
Expansion Slots 1 × PCIe 4.0/3.0 x16 (PCI_E1)2 × PCIe 3.0 x1
Graphics Ports 1 × VGA (max 2048×1536 @50Hz)1 × DisplayPort (max 4096×2160 @60Hz)1 × HDMI 2.1 (max 4096×2160 @60Hz, HDCP 1.4 & 2.3)Max shared memory: 16 GB
Storage 4 × SATA 6Gb/s2 × M.2 slots (M-Key)M2_1 (from CPU): PCIe 4.0/3.0 x4, SATA 6Gb/s, 2242/2260/2280M2_2 (from B550): PCIe 3.0 x4, 2242/2260/2280
RAID Support RAID 0, 1, 10 for SATA; RAID 0, 1 for M.2 NVMe
USB Ports AMD B550: 3 × USB 3.2 Gen 1 (1 Type-C internal, 2 via internal header), 6 × USB 2.0 (2 back, 4 internal)AMD Processor: 4 × USB 3.2 Gen 1 Type-A (back panel)
Audio Realtek® ALC892/ALC897 Codec, 7.1-Channel HD Audio
LAN 1 × Realtek® 8111HN Gigabit LAN
Wireless LAN & Bluetooth Wi-Fi AC (2.4/5GHz, up to 433 Mbps), Bluetooth 2.1–4.2
Internal Connectors 24-pin ATX, 8-pin CPU, 4 × SATA, 2 × M.2, USB 3.2 Gen 1 Type-C, USB 3.2 Gen 1 header, USB 2.0 headers, CPU fan, water pump fan, 3 × system fans, front panel audio, 2 × system panel, serial port, chassis intrusion, 2 × 4-pin RGB, 2 × 3-pin Rainbow, TPM module, Clear CMOS
Back Panel Ports VGA, HDMI 2.1, DisplayPort, LAN, PS/2 Combo, USB 3.2 Gen 1 ×2, USB 2.0 ×2, Flash BIOS button, Wi-Fi antenna connectors, 3 × audio jacks
Form Factor / Dimensions Micro-ATX, 9.6 × 9.6 in (24.4 × 24.4 cm), 8 mounting holes
Warranty 3 Years
